Description
Energy label
Technical Data Sheet
-
Frequency (Hz)50
-
Max absorbed current (A)1,0
-
Max absorbed power (W)105
-
Nominal diameter (mm)125
-
Voltage (V)230
-
Weight (Kg)27
-
Breakout sound power LWA [dB(A)]43,1
-
Breakout sound pressure at 3m at Max speed calculated in free field Lp [dB(A)]22,6
-
Max airflow (l/s)57,2
-
Max airflow (m³/h)206
-
Max pressure (mmH2O)43,5
-
Max pressure (Pa)426
-
Sound power at exhaust inlet LWA [dB(A)]36,5
-
Sound power at supply outlet LWA [dB(A)]43,3
-
Sound pressure at 3m at extraction at Max speed calculated in free field Lp [dB(A)]16,0
-
Sound pressure at 3m at supply at Max speed calculated in free field Lp [dB(A)]22,8
-
Ø (mm)125
-
Size A (mm)868
-
Size B (mm)643
-
Size C (mm)248
-
Size D (mm)963,5
-
Size E (mm)551
Interested?
If you are interested in this product, contact us or locate your nearest Vortice dealer.
Documentation
You can see all the documentation relating to this product: price list, information booklet and wiring diagram.
Accessories
Discover accessories related to the product
PANNELLO INSTALLATORE SKP10
Setting of machine parameters during initial installation procedures:
- speeds
- motors independently adjustable
- defrosting
- connection to any externa...
