Description
• Nominal diameter of blades 1400 mm
• Top and bottom motor covers moulded from heat-resistant and UV-resistant thermoplastic resin (ABS), colour white
• Wiring connections at end of ceiling rod concealed by domes moulded from impact- and UV-resistant PP, colour white.
• Single phase start capacitor motor with external rotor, and shaft turning in ball bearings. Direction of rotation reversible.
• Maximum air flow: 13,500 m3/h.
• 3 galvanized sheet steel blades powder coated with scratch-resistant polyester, colour white.
• Steel ceiling rod with polyester powder coated finish, colour white, length 375 mm.
• Bag of accessories containing nuts and bolts required for assembly of blades, ceiling hook and rubber anti-vibration washer.
• Speed selectable by way of control units (optional)
• Enclosure rating IPX5 ensuring complete protection from water spray.
• Top and bottom motor covers moulded from heat-resistant and UV-resistant thermoplastic resin (ABS), colour white
• Wiring connections at end of ceiling rod concealed by domes moulded from impact- and UV-resistant PP, colour white.
• Single phase start capacitor motor with external rotor, and shaft turning in ball bearings. Direction of rotation reversible.
• Maximum air flow: 13,500 m3/h.
• 3 galvanized sheet steel blades powder coated with scratch-resistant polyester, colour white.
• Steel ceiling rod with polyester powder coated finish, colour white, length 375 mm.
• Bag of accessories containing nuts and bolts required for assembly of blades, ceiling hook and rubber anti-vibration washer.
• Speed selectable by way of control units (optional)
• Enclosure rating IPX5 ensuring complete protection from water spray.
Certifications
-
Download
CE
-
EAC
-
CB TEST CERTIFICATE
Technical Data Sheet
-
Fan diameter1422
-
Frequency (Hz)50/60*
-
Insulation classI°
-
IPX5
-
Max absorbed current (A)0,33
-
Max absorbed power (W)70
-
Motor power (W)70
-
Voltage (V)220-240
-
Weight (Kg)6,70
-
Max airflow (m³/h)13500
-
Max airflow (m³/min)225,00
-
Max flow speed (m/s)1,69
-
RPM231
-
Service value (m³/min)/W3,214
-
Sound power Lw [dB(A)]52,1
* Technical datas above refer to the product powered at 50 Hz.
For values for 60 Hz power supply, please contact the VORTICE Presales Service at prevendita@vortice-italy.com.
-
Size A (mm)Ø 1422
-
Size B (mm)Ø 230
-
Size C (mm)495
