Description
• Scroll and front panel made of self-extinguishing ABS, rated V0.
• Motor housing and filter frame made of ABS plastic.
• 2 speed AC motor, shaft on ball bearings, coupled to a forward curved centrifugal impeller, PBT made.
• Nominal airflows: 100 / 60 m3/h
• G2 filter, with a clogged filter mechanic alarm fully compliant with ErP reg. N° 1253/2014/UE, in force since 1st January 2018.
• The fan is equipped with an infrared presence sensor (PIR – Passive InfraRed) that allows the instantaneous operation of the product when the sensor finds occupants; after the room has been left, the product stops to run with a settable delay (between 0 and 20 minutes). Is also possible to set, during the installation, the continuous running operation mode at minimum speed (Continuous Ventilation of the room), automatically moving to the higher speed through the presence detector.
• Motor housing and filter frame made of ABS plastic.
• 2 speed AC motor, shaft on ball bearings, coupled to a forward curved centrifugal impeller, PBT made.
• Nominal airflows: 100 / 60 m3/h
• G2 filter, with a clogged filter mechanic alarm fully compliant with ErP reg. N° 1253/2014/UE, in force since 1st January 2018.
• The fan is equipped with an infrared presence sensor (PIR – Passive InfraRed) that allows the instantaneous operation of the product when the sensor finds occupants; after the room has been left, the product stops to run with a settable delay (between 0 and 20 minutes). Is also possible to set, during the installation, the continuous running operation mode at minimum speed (Continuous Ventilation of the room), automatically moving to the higher speed through the presence detector.
Certifications
-
IMQ
-
Download
CE
-
TUV SUD
-
DIBt
Technical Data Sheet
-
Frequency (Hz)50
-
Insulation classII°
-
IP45
-
Max absorbed current at Max speed (A)0,17
-
Max absorbed current at Min speed (A)0,14
-
Max absorbed power at Max speed (W)26
-
Max ambient temperature for continuous operation (°C)50
-
Nominal diameter (mm)80
-
Ø Discharge hole (mm)70
-
Power absorbed at 1st speed (W)16
-
Voltage (V)220-240
-
Weight (Kg)2,33
-
Airflow at 1st speed (l/s)16,7
-
Airflow at 1st speed (m³/h)60
-
Max airflow at Max speed (l/s)27,8
-
Max airflow at Max speed (m³/h)100
-
Max pressure at Max speed (mmH20)36
-
Max pressure at Max speed (Pa)353
-
Max RPM1570
-
Min RPM1170
-
Pressure at 1st speed (mmH20)35
-
Pressure at 1st speed (Pa)343
-
Sound power at Min speed LWA [dB(A)]43
-
Sound power at Min speed LWA [dB(A)]48
-
Sound pressure at 3m at Max speed calculated in free field Lp [dB(A)]30,5
-
Sound pressure at 3m at Min speed calculated in free field Lp [dB(A)]25,5
-
Size A (mm)262
-
Size B (mm)262
-
Size C (mm)115,5
-
Size D (mm)80
-
Size E (mm)73
-
Size F (mm)79
-
Size G (mm)71,5
-
Size H (mm)90
