Description
• Scroll and front panel made of self-extinguishing ABS, rated V0.
• Motor housing and filter frame made of ABS plastic.
• 3 speed AC motor, shaft on ball bearings, coupled to a forward curved centrifugal impeller, PBT made.
• Nominal airflows: 100 / 60 / 35 m3/h
• G2 filter, with a clogged filter mechanic alarm fully compliant with ErP reg. N° 1253/2014/UE, in force since 1st January 2018.
• The switching on/off of the product can be realized through a dedicated external switch or the light control. Different level of performances, or rather the transition from Min to Max speed, can be realized through an external switch. During the installation, is also possible to set the continuous running mode at minimum speed (Continuous Ventilation of the room), moving to an higher speed selection (Boost mode) through the external switch.
• Motor housing and filter frame made of ABS plastic.
• 3 speed AC motor, shaft on ball bearings, coupled to a forward curved centrifugal impeller, PBT made.
• Nominal airflows: 100 / 60 / 35 m3/h
• G2 filter, with a clogged filter mechanic alarm fully compliant with ErP reg. N° 1253/2014/UE, in force since 1st January 2018.
• The switching on/off of the product can be realized through a dedicated external switch or the light control. Different level of performances, or rather the transition from Min to Max speed, can be realized through an external switch. During the installation, is also possible to set the continuous running mode at minimum speed (Continuous Ventilation of the room), moving to an higher speed selection (Boost mode) through the external switch.
Certifications
-
Download
CE
-
TUV SUD
-
DIBt
-
CB TEST CERTIFICATE
Technical Data Sheet
-
Frequency (Hz)50
-
Insulation classII°
-
IP45
-
Max absorbed current at Max speed (A)0,17
-
Max absorbed current at Mid speed (A)0,14
-
Max absorbed current at Min speed (A)0,11
-
Max absorbed power at Max speed (W)26
-
Max absorbed power at Mid speed (W)16
-
Max ambient temperature for continuous operation (°C)50
-
Nominal diameter (mm)80
-
Ø Discharge hole (mm)70
-
Power absorbed at 1st speed (W)9
-
Voltage (V)220-240
-
Weight (Kg)2,33
-
Airflow at 1st speed (l/s)9,7
-
Airflow at 1st speed (m³/h)35
-
Max airflow at Max speed (l/s)27,8
-
Max airflow at Max speed (m³/h)100
-
Max airflow at Mid speed (m³/h)60
-
Max airflow at Min speed (l/s)16,7
-
Max pressure at Max speed (mmH20)36
-
Max pressure at Max speed (Pa)353
-
Max pressure at Mid speed (mmH2O)35
-
Max pressure at Mid speed (Pa)343
-
Max RPM1570
-
Min RPM855
-
Pressure at 1st speed (mmH20)10
-
Pressure at 1st speed (Pa)98
-
RPM at Mid speed1170
-
Sound power LWA at Mid speed [dB (A)]43
-
Sound power at Min speed LWA [dB(A)]38
-
Sound power at Min speed LWA [dB(A)]48
-
Sound pressure at 3 m - min speed Lp [dB (A)] 3m - min speed20,5
-
Sound pressure at 3m at Max speed Lp [dB (A)]30,5
-
Sound pressure at 3m at Min speed Lp [dB (A)]25,5
-
Size A (mm)262
-
Size B (mm)262
-
Size C (mm)115,5
-
Size D (mm)80
-
Size E (mm)73
-
Size F (mm)79
-
Size G (mm)71,5
-
Size H (mm)90
