Description
Technical Data Sheet
-
Frequency (Hz)50-60
-
Insulation classII°
-
IPX0
-
Nominal power (W)45
-
Voltage (V)220-240
-
Weight (Kg)2,37
-
Max airflow (m³/h)846
-
Max airflow (m³/min)14,1
-
Max flow speed (m/s)3,4
-
Power in stand-by mode (W)0,2
-
Seasonal electric consumption (kWh/y)10,8
-
Service value (m³/min)/W0,4
-
Sound power Lw [dB(A)]60
-
Size A (mm)Ø 250
-
Size B (mm)Ø 250
-
Size C (mm)350
-
Size D (mm)131
-
Size E (mm)198
