Description

• Base manufactured from phosphated pressed steel, epoxy powder coated with hammered effect finish, guaranteeing long-term resistance to atmospheric agents.
• Aerodynamically contoured inlet port for optimum performance, fashioned as a single unit with the base and gauged to optimize air flow.
• Pressed steel motor cover: pickled and phosphated surface, polyester powder coated and oven baked finish, colour grey, with hammered texture.
• Pressed steel side baffles angled to exhaust extracted air upwards: zinc-coated, pickled and phosphated surface, polyester powder coated and oven baked finish, colour grey, with hammered texture.
• Accident prevention and anti-bird grilles (to UNI ISO 13857 standard), consisting of electrically welded steel rings with epoxy powder coated finish, colour black.
• Centrifugal impeller with self-cleaning backward curved steel blades, hot-dip galvanized and dynamically balanced (UNI ISO 1940, Point 1 – Class 6.3), and splined steel hub.
• 1 speed three-phase AC motor, size to UNEL MEC standard, flange B5, with shaft turning in double shielded ball bearings, insulation class H.
• Cooling fan for better dissipation of heat
• Galvanized steel eye lugs for transport and lifting/handling operations.
• Cable guaranteeing continuity of earth connection.
• Steel safety wire for anchoring appliances once installed.
• Vortice speed controller.
Read full descriptionClose description

Certifications

  • CE CE
  • EAC EAC

Technical Data Sheet

  • Frequency (Hz)
    50
  • Insulation class
  • Max absorbed current (A)
    3,25
  • Max absorbed power (W)
    1900
  • Max ambient temperature for continuous operation (°C)
    70
  • Motor protection IP
    55
  • Nominal diameter (mm)
    400
  • Number of phases (Ph)
    3
  • Number of poles
    4
  • Voltage (V)
    400
  • Weight (Kg)
    107
  • Max airflow (l/s)
    2778
  • Max airflow (m³/h)
    10000
  • Max pressure (mmH2O)
    84,5
  • Max pressure (Pa)
    830
  • RPM
    1420
  • Sound pressure Lp [dB (A)] at 3 m
    84
  • Dimension Q (mm)
    Ø 12
  • Size A (mm)
    1144
  • Size B (mm)
    830
  • Size C (mm)
    750
  • Size D (mm)
    860
  • Size E (mm)
    491
  • Size F (mm)
    38
  • Size G (mm)
    40
  • Size H (mm)
    723
  • Size L (mm)
    365
  • Size M (mm)
    Ø 375
  • Size N (mm)
    Ø 564
quota
Interested?
If you are interested in this product, contact us or locate your nearest Vortice dealer.

Accessories

Discover accessories related to the product

TR-G 70/100 (GRIGLIA DI PROTEZIONE)
TR-G 70/100 (GRIGLIA DI PROTEZIONE)
Intake port protection grille for use when the unit is mounted within reach.
TR-B 70/100 (BOCCAGLIO ASPIRAZIONE)
TR-B 70/100 (BOCCAGLIO ASPIRAZIONE)
Intake nozzle to fit on intake side for optimizing intake and reducing noise level.
TR-CU 70/100    (CONTROTELAIO DI BASE U)
TR-CU 70/100 (CONTROTELAIO DI BASE U)
Installation base counter-frame.
TR-S 70/100 (SERRANDA A GRAVITA')
TR-S 70/100 (SERRANDA A GRAVITA')
Galvanized sheet-metal gravity backdraught shutter.
• With aluminium shutters and return spring, for preventing air backdraughts or penetration of rain when the unit ...
