Description
Technical Data Sheet
-
Frequency (Hz)50
-
Insulation classI°
-
IP65
-
Max absorbed current (A)0,49
-
Max absorbed power (W)140
-
Max ambient temperature for continuous operation (°C)+ 40
-
Min continuous operation room temperature (°C)- 20
-
Nominal diameter (mm)316
-
Number of phases (Ph)3
-
Number of poles4
-
Number of speeds1
-
Voltage (V)400
-
Weight (Kg)8,0
-
Max airflow (l/s)503,0
-
Max airflow (m³/h)1811
-
Max pressure (mmH2O)17,3
-
Max pressure (Pa)170
-
RPM1400
-
Sound pressure Lp [dB (A)] at 3 m51,3
-
Ø (mm)315
-
Size A (mm)380
-
Size B (mm)380
-
Size C (mm)307
-
Size D (mm)330
-
Size E (mm)308
-
Size F (mm)300
-
Size G (mm)97
-
Size H (mm)8
-
Size L (mm)10
-
Size M (mm)325
-
Size N (mm)316
