Description
Technical Data Sheet
-
Absorbed power - Cooling mode (W)750
-
Absorbed power - Heating mode (W)745
-
Additional refrigerant charge (g/m)20
-
Compressor typeInverter rotativo
-
Condensate draining pipe Ø (mm)15,6
-
Energy class in cooling modeA++
-
Energy class in heating modeA+
-
Frequency (Hz)50
-
Insulation classI°
-
Max height difference (m)10
-
Max lenght of cooling pipes (m) - I.U.20
-
Max lenght of cooling pipes with standard charge of refrigerant5
-
Max pipe lenght (m)20
-
Nominal current - Cooling mode (A)3,60
-
Nominal current - Heating mode (A)3,40
-
Number of phases (Ph)1
-
Refrigerant pipe Ø (inch)1/4"-3/8"
-
Refrigerant typeR32
-
Standard refrigerant charge (g)520
-
Voltage (V)220-240
-
Weight (Kg)9
-
Cooling capacity (BTU/h)8.871
-
Cooling capacity (W)2.600
-
COP (Coefficient of Performance)3,76
-
Flow rate in cooling mode I.U. (SH-H-M-L) (m³/h)520/440/230/150
-
Heating capacity (BTU/h)9.554
-
Heating capacity (W)2.800
-
Indoor operation temperature (cooling/heating) (°C)-15~52/-15~24
-
Outdoor operation temperature (cooling/heating) (°C)16~31
-
SCOP4,00
-
SEER6,70
-
Sound power I.U. UI (SH-H-M-L) [dB(A)]50/45/43/37
-
Sound pressure I.U. at 1m calculated in free field (SH-H-M-L) [dB(A)]39/34/32/26
-
Suggested surface of destination room (m2)12-18
-
Size A (mm)792
-
Size B (mm)279
-
Size C (mm)195
Interested?
If you are interested in this product, contact us or locate your nearest Vortice dealer.
Documentation
You can see all the documentation relating to this product: price list, information booklet and wiring diagram.
