Description
Technical Data Sheet
-
Weight (Kg)1,30
-
DExt (mm)558
-
Dimension B2 (mm)8x45°
-
Dimension B3 (mm)12
-
Dimension C2 (mm)12x30°
-
Dimension C3 (mm)11
-
Dimension R=S (mm):35
-
DInt (mm)559
-
Size A (mm)650
-
Size B (mm)608
-
Size B1 (mm)629
-
Size C (mm)608
-
Size D (mm)629
-
Size D2 (mm)16x22,5°
-
Size D3 (mm)12
-
Size P (mm)70
